Chapter 6



Analytical techniques and solutions for plastic solids







6.2 Bounding theorems in plasticity and their applications



To set the background for plastic limit analysis, it is helpful to review the behavior of an elastic-plastic solid or structure subjected to mechanical loading.  The solution to an internally-pressurized elastic-perfectly plastic sphere given in Section 4.2 provides a representative example.  All elastic-perfectly plastic structures will exhibit similar behavior.  In particular

 An inelastic solid will reach yield at some critical value of applied load.

 If the load exceeds yield, a plastic region starts to spread through the solid. As an increasing area of the solid reaches yield, the displacements in the structure progressively increase.

 At a critical load, the plastic region becomes large enough to allow unconstrained plastic flow in the solid. The load cannot be increased beyond this point. The solid is said to collapse.



Strain hardening will influence the results quantitatively, but if the solid has a limiting yield stress (a stress beyond which it can never harden) its behavior will be qualitatively similar.



In a plasticity calculation, often the two most interesting results are (a) the critical load where the solid starts to yield; and (b) the critical load where it collapses.  Of course, we don’t need to solve a plasticity problem to find the yield point  we only need the elastic fields.  In many design problems this is all we need, since plastic flow must be avoided more often than not.  But there are situations where some plasticity can be tolerated in a structure or component; and there are even some situations where it’s desirable (e.g. in designing crumple zones in cars).  In this situation, we usually would like to know the collapse load for the solid.  It would be really nice to find some way to get the collapse load without having to solve the full boundary value problem.



This is the motivation for plastic limit analysis.  The limit theorems of plasticity provide a quick way to estimate collapse loads, without needing any fancy calculations.  In fact, collapse loads are often much easier to find than the yield point!



In this section, we derive several useful theorems of plastic limit analysis and illustrate their applications.





6.2.1 Definition of the plastic dissipation



Consider a rigid perfectly plastic solid, which has mass density , and a Von-Mises yield surface with yield stress in uniaxial tension Y. (By definition, the elastic strains are zero in a rigid plastic material). The solid is subjected to tractions  on the its boundary.  The solid may also be subjected to a body force b (per unit mass) acting on the interior of the solid.  Assume that the loading is sufficient to cause the solid to collapse.





Velocity discontinuities: Note that the velocity and stress fields in a collapsing rigid plastic solid need not necessarily be continuous.  The solution often has shear discontinuities, as illustrated on the right.  In the picture, the top part of the solid slides relative to the bottom part.  We need a way to describe this kind of deformation.  To do so,



1.       We assume that the velocity field  at collapse may have a finite set of such shear discontinuities, which occur over a collection of surfaces .  Let m be a unit vector normal to the surface at some point , and let    denote the limiting values of velocity and stress  on the two sides of the surface.

2.       To ensure that no holes open up in the material, the velocity discontinuity must satisfy



3.       The solids immediately adjacent to the discontinuity exert equal and opposite forces on each other.  Therefore



4.       We will use the symbol  to denote the relative velocity of sliding across the discontinuity, i.e.



5.       The yield criterion and plastic flow rule require that  on any surfaces of velocity discontinuity.



Kinematically admissible collapse mechanism: The kinematically admissible collapse mechanism is analogous to the kinematically admissible displacement field that was introduced to define the potential energy of an elastic solid.  By definition, a kinematically admissible collapse mechanism is any velocity field v satisfying  (i.e. v is volume preserving)

Like u, the virtual velocity v may have a finite set of discontinuities across surfaces  with normal  (these are not necessarily the discontinuity surfaces for the actual collapse mechanism).  We use



to denote the magnitude of the velocity discontinuity. We also define the virtual strain rate



 (note that  ) and the effective virtual plastic strain rate





Plastic Dissipation: Finally, we define the plastic dissipation associated with the virtual velocity field v as



The terms in this expression have the following physical interpretation:

1.       The first integral represents the work dissipated in plastically straining the solid;

2.       The second integral represents the work dissipated due to plastic shearing on the velocity discontinuities;

3.       The third integral is the rate of mechanical work done by body forces

4.       The fourth integral is the rate of mechanical work done by the prescribed surface tractions.







6.2.2. The Principle of Minimum Plastic Dissipation



Let  denote the actual velocity field that causes a rigid plastic solid to collapse under a prescribed loading.  Let v be any kinematically admissible collapse mechanism.  Let  denote the plastic dissipation, as defined in the preceding section.  Then

1.

2.

Thus,  is an absolute minimum for  - in other words, the actual velocity field at collapse minimizes .  Moreover,  is zero for the actual collapse mechanism.



Derivation: Begin by summarizing the equations governing the actual collapse solution. Let  denote the actual velocity, strain rate and stress in the solid at collapse. Let  denote the deviatoric stress. The fields must satisfy governing equations and boundary conditions

 Strain-displacement relation

 Stress equilibrium

 Plastic flow rule and yield criterion



On velocity discontinuities, these conditions require that

 Boundary conditions





We start by showing that

1.       By definition



2.       Note that, using (i) the flow rule, (ii) the condition that  and (iii) the yield criterion



3.       Note that  from the symmetry of . Hence



4.       Note that .  Substitute into the expression for , combine the two volume integrals and recall (equilibrium) that  to see that



5.       Apply the divergence theorem to the volume integral in this result.  When doing so, note that we must include contributions from the velocity discontinuity across S as follows



6.       Finally, recall that  on the boundary, and note that the outward normals to the solids adjacent to S are related to m  by  .  Thus



Since , we find that  as required.



Next, we show that .  To this end,

1.       Let  be a kinematically admissible velocity field as defined in the preceding section, with strain rate



2.       Let  be the stress necessary to drive the kinematically admissible collapse mechanism, which must satisfy the plastic flow rule and the yield criterion



3.       Recall that the plastic strains and stresses associated with the kinematically admissible field must satisfy the Principle of Maximum Plastic Resistance (Section 3.7.10), which in the present context implies that



To see this, note that  is the stress required to cause the plastic strain rate  , while the actual stress state at collapse  must satisfy .

4.       Note that .  Substituting into the principle of maximum plastic resistance and integrating over the volume of the solid shows that



5.       Next, note that



6.       The equilibrium equation shows that .  Substituting this into the result of (5) and then substituting into the result of (4) shows that



7.       Apply the divergence theorem to the second integral. When doing so, note that we must include contributions from the velocity discontinuity across  as follows



8.       Recall that  on the boundary, and note that the outward normals to the solids adjacent to S are related to m  by  .  Thus



9.       Finally, note that on



since the shear stress acting on any plane in the solid cannot exceed .  Thus



 proving that  as required.





6.2.3 The Upper Bound Plastic Collapse Theorem



Consider a rigid plastic solid, subjected to some distribution of tractions  and body forces .  We will attempt to estimate the factor  by which the loading can be increased before the solid collapses (  is effectively the factor of safety).  We suppose that the solid will collapse for loading , .



To estimate , we guess the mechanism of collapse.  The collapse mechanism will be an admissible velocity field, which may have a finite set of discontinuities across surfaces  with normal , as discussed in 6.2.1.



The principle of minimum plastic dissipation then states that



for any collapse mechanism, with equality for the true mechanism of collapse. Therefore



Expressed in words, this equation states that we can obtain an upper bound to the collapse loads by postulating a collapse mechanism, and computing the ratio of the plastic dissipation associated with this mechanism to the work done by the applied loads.



So, we can choose any collapse mechanism, and use it to estimate a safety factor.  The actual safety factor is likely to be lower than our estimate (it will be equal if we guessed right).  This method is evidently inherently unsafe, since it overestimates the safety factor  but it is usually possible guess the collapse mechanism quite accurately, and so with practice you can get excellent estimates.





6.2.4 Examples of applications of the upper bound theorem



Example 1: collapse load for a uniaxial bar. We will illustrate the bounding theorems using a few examples.  First, we will compute  bounds to the collapse load for a uniaxial bar.  Assume the bar has unit out of plane thickness, for simplicity.



To get an upper bound, we guess a collapse mechanism as shown below.  The top and bottom half of the bar slide past each other as rigid blocks, as shown, with a velocity discontinuity across the line shown in red.



The upper bound theorem gives



In this problem the strain rate vanishes, since we assume the two halves of the bar are rigid.  The plastic dissipation is



The body force vanishes, and



where  is the vertical component of the velocity of the top block.  Thus



The best upper bound occurs for , giving  for the collapse load.







Example 2: Collapse load for a bar containing a hole. For a slightly more interesting problem, consider the effect of inserting a hole with radius a in the center of the column.  This time we apply a force to the top of the column, rather than specify the traction distribution in detail.  We will accept any solution that has traction acting on the top surface that is statically equivalent to the applied force.



A possible collapse mechanism is shown.  The plastic dissipation is



The rate of work done by applied loading is



Our upper bound follows as



and the best upper bound solution is



Example 3: Force required to indent a rigid platic surface. For our next example, we attempt to find upper and lower bounds to the force required to push a flat plane punch into a rigid plastic solid.  This problem is interesting because we have an exact slip-line field solution, so we can assess the accuracy of the bounding calculations.



A possible collapse mechanism is shown above.  In each semicircular region we assume a constant circumferential velocity .  To compute the plastic dissipation in one of the regions, adopt a cylindrical-polar coordinate system with origin at the edge of the contact.  The strain distribution follows as



Thus the plastic dissipation is



(note that there’s a velocity discontinuity at r=a). The work done by applied loading is just  giving the upper bound



This should be compared to the exact slip-line field solution



computed in section 6.1.  The error is 17% - close enough for government work.







Example 4: Orthogonal metal cutting. The picture shows a simple model of machining.  The objective is to determine the horizontal force P acting on the tool (or workpiece) in terms of the depth of cut h, the tool rake angle  and the shear yield stress of the material



To perform the calculation, we adopt a reference frame that moves with the tool.  Thus, the tool appears stationary, while the workpiece moves at speed  to the right.  The collapse mechanism consists of shear across the red line shown in the picture.



Elementary geometry gives the chip thickness d as



Mass conservation (material flowing into slip discontinuity = material flowing out of slip discontinuity) gives the velocity of material in the chip  as



The velocity discontinuity across the shear band is



The plastic dissipation follows as



The upper bound theorem gives



To obtain the best estimate for P, we need to minimize the right hand side of this expression with respect to .  This gives



The resulting upper bound to the machining force is plotted on the figure to the right.









6.2.5 The Lower Bound Plastic Collapse Theorem



The lower bound theorem provides a safe estimate of the collapse loads for a rigid plastic solid.



Consider a rigid plastic solid, subjected to some distribution of tractions  and body forces .  We will attempt to estimate the factor  by which the loading can be increased before the solid collapses (  is effectively the factor of safety).  We suppose that the solid will collapse for loading , .



To estimate , we guess the distribution of stress in the solid at collapse.

We will denote the guess for the stress distribution by .  The stress distribution must

1.       Satisfy the boundary conditions , where  is a lower bound to

2.       Satisfy the equations of equilibrium  within the solid,

3.       Must not violate the yield criterion anywhere within the solid,



The lower bound theorem states that if any such stress distribution can be found, the solid will not collapse, i.e. .



Derivation

1.       Let  denote the actual velocity field in the solid at collapse.  These must satisfy the field equations and constitutive equations listed in Section 6.4.4.

2.       Let  denote the guess for the stress field.

3.       The Principle of Maximum Plastic Resistance (see Section 3.7.10) shows that , since  is at or below yield.

4.       Integrating this equation over the volume of the solid, and using the principle of virtual work on the two terms shows that



 This proves the theorem.







6.2.6 Examples of applications of the lower bound plastic collapse theorem



Example 1: Collapse load for a plate containing a hole.  A plate with width L contains a hole of radius a at its center.  The plate is subjected to a tensile force P as shown (the traction distribution is not specified in detail we will accept any solution that has traction acting on the top surface that is statically equivalent to the applied force).



For a statically admissible stress distribution, we consider the stress field shown in the figure, with , and all other stress components zero.



The estimate for the applied load at collapse follows as







Example 2: Rigid indenter in contact with a half-space.  We consider a flat indenter with width a that is pushed into the surface of a half-space by a force P.  The stress state illustrated in the figure will be used to obtain a lower bound to the collapse load in the solid.   Note that

1.       Regions C, E, F are stress free

2.       The stress in regions A and D consists of a state of uniaxial stress, with direction parallel to the boundaries between AC (or AE) and CD (or DF) respectively.  We will denote this stress by , where m is a unit vector parallel to the direction of the uniaxial stress.

3.       The stress state in the triangular region B has principal directions of stress parallel to . We will write this stress state as

The stresses in each region must be chosen to satisfy equilibrium, and to ensure that the stress is below yield everywhere.   The stress is constant in each region, so equilibrium is satisfied locally.  However, the stresses are discontinuous across AC, AB, etc.  To satisfy equilibrium, equal and opposite tractions must act on the material surfaces adjacent to the discontinuity, which requires, e.g. that , where n is a unit vector normal to the boundary between A and B as indicated in the figure.  We enforce this condition as follows:

1.       Note that

2.       Equilibrium across the boundary between A and B requires



3.       We must now choose  and  to maximize the collapse load, while ensuring that the stresses do not exceed yield in regions A or B.   Clearly, this requires ; while  must be chosen to ensure that .  This requires .   The largest value for  maximizes the bound.

4.       Finally, substituting for  gives .  We see that the lower bound is .











6.2.7 The lower bound shakedown theorem



In this and the next section we derive two important theorems that can be used to estimate the maximum cyclic loads that can be imposed on a component without exceeding yield.  The concept of shakedown in a solid subjected to cyclic loads was introduced in Section 4.2.4, which discusses the behavior of a spherical shell subjected to cyclic internal pressure.   It was shown that, if the first cycle of pressure exceeds yield, residual stresses are introduced into the shell, which may prevent further plastic deformation under subsequent load cycles.  This process is known as shakedown, and the maximum load for which it can occur is known as the shakedown limit



We proceed to derive a theorem that can be used to obtain a safe estimate to the maximum cyclic load that can be applied to a structure without inducing cyclic plastic deformation.



We consider an elastic-perfectly plastic solid with Von-Mises yield surface, associated flow law, and uniaxial tensile yield stress Y. Assume that

1.       The displacement  on part of the boundary of the solid

2.       The remainder of the boundary   is subjected to a prescribed cycle of traction .   The history of traction is periodic, with a period T.



Define the following quantities:

1.       Let  denote the actual history of displacement, strain and stress induced in the solid by the applied loading.  The strain is partitioned into elastic and plastic parts as

2.       Let  denote the history of displacement, strain and stress induced by the prescribed traction in a perfectly elastic solid with identical geometry.

3.       We introduce (time dependent) residual stress  and residual strain  fields, which (by definition) satisfy



Note that, (i) because  on , it follows that  on  ; and (ii) because  it follows that



The lower bound shakedown theorem can be stated as follows: The solid is guaranteed to shake down if any time independent residual stress field  can be found which satisfies:

 The equilibrium equation ;

 The boundary condition  on  ;

 When the residual stress is combined with the elastic solution, the combined stress does not exceed yield  at any time during the cycle of load.



The theorem is valuable because shakedown limits can be estimated using the elastic solution, which is much easier to calculate than the elastic-plastic solution.



Proof of the lower bound theorem:  The proof is one of the most devious in all of solid mechanics.

1.       Consider the strain energy associated with the difference between the actual residual stress field , and the guess for the residual stress field , which can be calculated as



where  is the elastic compliance tensor.   For later reference note that W has to be positive, because strain energy density is always positive or zero.

2.       The rate of change of W can be calculated as



(to see this, recall that  )

3.       Note that . Consequently, we see that



4.       Using the principle of virtual work, the second integral can be expressed as an integral over the boundary of the solid



To see this, note that  on , while  on

5.       The remaining integral in (3) can be re-written as



6.       Finally, recall that  lies at or below yield, while  is at yield and is the stress corresponding to the plastic strain rate .   The principle of maximum plastic resistance therefore shows that .  This inequality and   can only be satisfied simultaneously if .  We conclude that either the plastic strain rate vanishes, or .  In either case the solid must shake down to an elastic state.







6.2.8 Examples of applications of the lower bound shakedown theorem



Example 1: A simple 3 bar problem.  It is traditional to illustrate the concept of shakedown using this problem.  Consider a structure made of three parallel elastic-plastic bars, with Young’s modulus E and cross sectional are A, as shown in the figure.  The two bars labeled 1 and 2 have yield stress Y; the central bar (labeled 3) has yield stress 2Y.  The structure is subjected to a cyclic load with mean value  and amplitude .



The elastic limit for the structure is ; the collapse load is .



To obtain a lower bound to the shakedown limit, we must

1.       Calculate the elastic stresses in the structure  the axial stress in each bar is

2.       Find a residual stress distribution in the structure, which satisfies equilibrium and boundary conditions, and which can be added to the elastic stresses to bring them below yield.   A suitable residual stress distribution consists of an axial stress  in bars 1, 2 and 3. To prevent yield at the maximum and minimum load in all three bars, we require



The first two equations show that , irrespective of .  To avoid yield in all bars at the maximum load, we must choose , which gives . Similarly, to avoid yield in all bars at the minimum load, we must choose , showing that .





The various regimes of behavior are summarized in the figure.









Example 2: Shakedown limit for a pressurized spherical shell.  We consider an elastic-perfectly plastic thick-walled shell, with inner radius a and outer radius b.  The inner wall of the shell is subjected to a cyclic pressure, with minimum value zero, and maximum value



To estimate the shakedown limit we must

1.       Calculate the stresses induced by the pressure in an elastic shell.  The solution can be found in Section 4.1.4.



2.       Find a self-equilibrating residual stress field, which satisfies traction free boundary conditions on R=a, R=b, and which can be added to the elastic stresses to prevent yield in the sphere.  The equilibrium equation for the residual stress can be written



We can satisfy this equation by choosing any suitable distribution for  and calculating the corresponding .  For example, we can choose , which corresponds to .  To avoid yield at maximum load, we must ensure that , while to avoid yield at zero load,  throughout the shell.   The critically stressed material element lies at R=a at both the maximum and zero loads, which shows that



Clearly, the best choice of  is



The estimate for the shakedown limit therefore follows as .  This is equal to the exact solution derived (with considerably more effort) in Section 4.1.4.









6.2.9 The Upper Bound Shakedown Theorem



In this section we derive a theorem that can be used to obtain an over-estimate to the maximum cyclic load that can be applied to a structure without inducing cyclic plastic deformation.  Although the estimate is inherently unsafe, the theorem is easier to use than the lower bound theorem.



We consider an elastic-perfectly plastic solid with Von-Mises yield surface, associated flow law, and uniaxial tensile yield stress Y. Assume that

1.       The displacement  on part of the boundary of the solid

2.       The remainder of the boundary   is subjected to a prescribed cycle of traction .   The history of traction is periodic, with a period T.



Define the following quantities:

1.       Let  denote the actual history of displacement, strain and stress induced in the solid by the applied loading.  The strain is partitioned into elastic and plastic parts as

2.       Let  denote the history of displacement, strain and stress induced by the prescribed traction in a perfectly elastic solid with identical geometry.

To apply the upper bound theorem, we guess a mechanism of cyclic plasticity that might occur in the structure under the applied loading.  We denote the cycle of strain by , and define the change in strain per cycle as



To be a kinematically admissible cycle,

  must be compatible, i.e.   for some a displacement field .  Note that only the change in strain per cycle needs to be compatible, the plastic strain rate need not be compatible at every instant during the cycle.

 The compatible displacement field must satisfy  on .



The upper bound shakedown theorem can then be stated as follows.  If there exists any kinematically admissible cycle of strain that satisfies



the solid will not shake down to an elastic state.



Proof: The upper bound theorem can be proved by contradiction.

  1. Suppose that the solid does shake down.  Then, from the lower bound shakedown theorem, we know that there exists a time independent residual stress field , which satisfies equilibrium ; the boundary conditions   on  , and is such that  lies below yield throughout the cycle.
  2. The principle of maximum plastic resistance then shows that .  Integrating this expression over the volume of the solid, and the cycle of loading gives



  1. Finally, reversing the order of integration in the last integral and using the principle of virtual work, we see that



To see this, note that   on  while   on  .

  1. Substituting this result back into (2) gives a contradiction, so proving the upper bound theorem.







6.2.10 Examples of applications of the upper bound shakedown theorem



Example 1: A simple 3 bar problem.  We re-visit the demonstration problem illustrated in Section 6.2.8.  Consider a structure made of three parallel elastic-plastic bars, with Young’s modulus E, length L, and cross sectional are A, as shown in the figure.  The two bars labeled 1 and 2 have yield stress Y; the central bar (labeled 3) has yield stress 2Y.  The structure is subjected to a cyclic load with mean value  and amplitude .



To obtain an upper bound to the shakedown limit, we must devise a suitable mechanism of plastic flow in the solid.  We could consider three possible mechanisms:

  1. An increment of plastic strain  in bars (1) and (2) at the instant of maximum load, followed by  in bars (1) and (2) at the instant of minimum load.  Since the strain at the end of the cycle vanishes, it is automatically compatible.
  2. An equal increment of plastic strain  in all three bars at each instant of maximum load
  3. An equal increment of plastic strain  at each instant of minimum load.



By finding the combination of loads for which



we obtain conditions where shakedown is guaranteed not to occur. Note that the elastic stresses in all three bars are equal, and are given by . Thus

  1. For mechanism (1):
  2. For mechanism (2):
  3. For mechanism (3):



These agree with the lower bound calculated in Section 6.2.8, and are therefore the exact solution.





Example 2: Shakedown limit for a pressurized spherical shell.  We consider an elastic-perfectly plastic thick-walled shell, with inner radius a and outer radius b.  The inner wall of the shell is subjected to a cyclic

pressure, with minimum value zero, and maximum value



To estimate the shakedown limit we must

1.       Calculate the stresses induced by the pressure in an elastic shell.  The solution can be found in Section 4.1.4.



  1. Postulate a mechanism of steady-state plastic deformation in the shell.  For example, consider a mechanism consisting of a uniform plastic strain increment  which occurs in a spherical shell with radius a very small thickness dt at the instant of maximum pressure, followed by a strain  at the instant of minimum load.

The upper bound theorem states that shakedown will not occur if



Substituting the elastic stress field and the strain rate shows that



This gives  for the shakedown limit.  Again, this agrees with the lower bound, and is therefore the exact solution.









(c) A.F. Bower, 2008
This site is made freely available for educational purposes.
You may extract parts of the text
for non-commercial purposes provided that the source is cited.
Please respect the authors copyright.
